Fail Secure electric bolt W/signal, time,& open wire(EL-700B)

EL-700B (LED) is an all-metal construction Fail Secure electric bolt .with 304 stainless steel solid bolt and 2000kg holding force. It can be worked at the temperature of 60 ℃ or -40 ℃ based on the all-metal linkage parts. With the multiple designs of durable magnetic valve, special photoelectric control system, ultra-low temperature and power consumption design, anti-intrusion and smart circuit.

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

Low Temperature, safe & Durable.

Low Power, Environmental Protection.

Special photo electricity control,three steps current application.

Long Life  with 500000 Operations.

MOV Provides Reverse Current Protection.

Superior Strength Aluminium Alloy,Solid Stainless Steel Bolt.

Autolock Time Delay: 0,3,6,9sec.

Lock signal:NO/NC/COM;Door signal:NO/COM.

Double protection for loading current.

Auto-relock if no Action within 5 secs.

Certificate:CE&MA.

Photo electricity Control,Low Temperature，

  A:The  Low Current is Changed immediately;

  B:When door frame doesn`t coincide with door leaf ,door leaf against the bolt,then the electric bolt will start the low-power function to bring low temperature.

  C:The Photo electricity Control Technology,prevent the mechanical defect.

N/A
Product Parameter Parameter Description
Feature Fail Secure
Face Plate 225Lx34WX38H(mm)
Strike 100Lx25Wx3W(mm)
Bolt 16(length)*16(diameter)(mm)
Voltage DC12V+10%
Start Current 1200mA
Standby Current 200mA
Solid Bolt polishing housing, 2000Kg Holding Force
Suitable For  Heavy door；Wooden door; Metal door
LED Light on indicates locked, light off indicates unlocked
Autolock Time Delay 0,3,6,9sec
Signal Output Lock signal:NO/NC/COM
Door signal:NO/COM
Surface Temp Low Temperature
Detection Distance Within 8mm
Special Designed Tested to 500000 cycles
Material 304 stainless steel, wire draw finishing
Weight 1.0kg
