Single Door Magnetic Mini Lock(EL-60)

EL-60 is a mini single door electric lock, it is designed for showcase, cabinet door and easy to install . The holding force is 120lbs.

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

Collinear Load Test 60kg,120pounds.

MOV Provides Reverse Current Protection.

Anti-Residual Magneism Designed.

High Strength Material,Anodized Aluminum Housing.

Design with no Mechanical Bolt.

Increase the holding Force,Dual Insulative Hosing.

CE Certificate by European Union,MA Certificate by China Public Security Office.
N/A
Product Parameter Parameter Description
Size 80Lx39Wx24.5H(mm)
Armature Plate Dimension 80Lx33Wx9.3H(mm)
Holding Force 60kg(120Lbs)
Input Voltage 12VDC
Current 12V/120mA
Suitable File Cabinet ,Display Cabinet
Surface Temp ≤+20℃
Operating Temp   -10~+55℃(14-131F)
Humidity 0~90%(non-condensing)
Cover Finish Anodized aluminum
Lock Finish  Zinc
Armature Plate Finish  Zinc
Weight  0.6KG

New product
