YM-750(LED) Single Door Magnetic Lock(LED)

YLI YM-750(LED) Single Door Magnetic Lock(LED)

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

YM-750(LED) single door electric lock with LED. Suitable for different types of door. Inbuilt dry contacts lock status signal output ( NO,NC,COM). Special anti-residual magnetism designed and with LED indicator.
Collinear Load Test 750kg, 1500pounds.
Dual Voltage 12 or 24 VDC(optional).
The Standard Voltage is 12VDC when Finished.
MOV Provides Reverse Current Protection.
Suitable For Wooden Door, Glass Door, Metal Door, Fireproof Door.
LED Indicates the Door Status.
Lock Status sensor(NO/NC/COM).
Anti-Residual Magnetism Designed.
High Strength Material, Anodized Aluminum Housing.
Design without Mechanical Failure.
Increase the holding Force, Dual Insulative Housing.
CE Certificate by European Union, MA Certificate by China Public Security Office.
Product Parameter Parameter Description
Size 280Lx81.6Wx46H(mm)
Armature plate 190Lx70Wx13H(mm)
Holding Force 750kg(1500Lbs)
Voltage DC12V (Adjustable DC24V)
Current Draw 12V/420mA; 24V/210mA
Signal Output Dry Contact, Max Rating of Contact Current 3A
LED Red indicates the door is unlocked, Green indicates the door is locked
Suitable for Wooden door, Glass door,Metal door, Fireproof door
Surface Temp ≤+20℃
Operating Temp -20℃~+55℃
Humidity 0~90%(non-condensing)
Finishes for Shell Anodized aluminum
Finishes for Magnetic Zinc
Finishes for Armature Zinc
Weight 5.9kg
