Single Door Magnetic Lock(LED) EL-280-DS

EL-280-DS inbuilt dry contacts lock status signal output ( NO,NC,COM),door status signal output ( NO,NC,COM) is the main selling point. Magnetic lock with 600lbs holding force for single door ,like glass door, wooden door, fireproof door, sliding door and metal door. It is also with LED indicator.

  • Overview

  • Feature

  • Specification

  • Configuration

  • Download

Collinear Load Test 280kg,600pounds.

Dual Voltage 12 or 24 VDC(optional).

The Standard Voltage is 12VDC when Finished.

MOV Provides Reverse Current Protection.

Suitable For Wooden Door,Glass Door,Metal Door,Fireproof Door.

LED Indicates the door Status.

Lock Status sensor(NO/NC/COM)

Door Status sensor(NO/NC/COM).

Anti-Residual Magnetism Designed.

High Strength Material,Anodized Aluminum Housing.

Design without Mechanical Failure.

Increase the holding Force,Dual Insulative Housing.

CE Certificate by European Union,MA Certificate by China Public Security Office.
N/A
Product Parameter Parameter Description
Size 250Lx48.5Wx25H(mm)
Armature Plate Dimension 180Lx38Wx11H(mm)
Holding Force 280kg(600Lbs)
Input Voltage 12 or 24VDC
Current 12V/500mA or 24V/250mA
LED Red indicates the door is unlock,Green indicates the door is lock
door status signal output NO,NC,COM
Suitable Wooden door , Glass door ,Metal door , Fireproof door
Surface Temp ≤+20℃
Operating Temp  -10~+55℃(14-131F)
Humidity  0~90%(non-condensing)
Cover Finish Anodized aluminum
Lock Finish Zinc
Armature Plate Finish Zinc
Weight 2.1KG

New product
